LTI 20/20 TruSpeed® Sxb

Description:

A multi-faceted speed lidar unit. Enforce speed, or combine with LaserSoft® apps for crash scene investigation.

SKU: 7007051

Overview Downloads Primary Applications Key Features Specs

Overview

The TruSpeed® Sxb is a dual speed and survey laser integrated with Bluetooth® communication. This lidar is iOS and Android compatible. Sporting the same features as the TruSpeed S, the addition of a built-in tilt sensor gives this laser the ability to measure both horizontal and vertical distance, ideal for crash scene mapping.

The TruSpeed Sxb integrates Bluetooth communication to allow syncing with our LaserSoft® SpeedCapture App. Pair this lidar unit with your smartphone to make this combination a formidable team in enforcing the speed limit as it captures and stores a picture of the offending vehicle. Collect time, speed, and distance data as well as the option to input vehicle and violation information, embed all this metadata within the photo file which can either be saved to your camera roll for texting and emailing, or export the whole data log to be downloaded onto a PC.

The TruSpeed Sxb has it all. A mighty multi-use tool for every department’s toolbox:

  • Use on its own for speed enforcement
  • Pair with your smartphone to use the LaserSoft® SpeedCapture app and enforce speed limits while capturing an image of the infraction of the offending vehicle.
  • Combine with LaserSoft SpeedStat software to perform speed assessments in your community. Easily collect speed records and review summary statistics.
  • Use this unit’s built-in tilt sensor, to measure horizontal and vertical distances for crash scene mapping.





*Bracket is shown for illustration purposes only.

*We work with and currently recommend Phone Skope brackets (https://phoneskope.com/builder/).

Downloads

LTI 20/20 Product Solutions Brochure Download

Key Features

In-scope display with 7x magnification

The 7x magnification viewing lens helps prevent eye fatigue, leading to longer speed enforcement sessions. The blackmask in-scope LCD equips you to see clearly in all lighting conditions.

Bluetooth Communication

Allows the operator to use their smartphone and sync up with LaserSoft SpeedCapture app to store a picture of the offending vehicle.

Built-in Tilt Sensor

Gives the laser the ability to measure both horizontal and vertical distances for crash scene mapping.

Specifications

Weight

0.9 lb

Size (L x W x H)

5.2 x 4.5 x 2.1 in.

Construction

Glass-Filled Polycarbonate Composite

Maximum Range

2,000 ft

Speed Range

± 200 mph

Range Accuracy
  • Speed Mode: ± 6 in
  • Survey Mode:
    • Typical:± 1.6 in
    • Maximum: ± 6 in
Speed Accuracy

± 1 mph

Power

(1) CR 123A battery (12 hours of operation time)

Environmental

Water resistant; NEMA 4; IP 55

Operating Temperature

-22° to 140° F

Storage Temperature

-31° to 158° F

Eye Safety

Class 1/FDA CFR 21

Bluetooth

Class 2, Ver. 2.1, Backwards compatible, 128-bit encryption, iOS/Android
